20 Piece (MOQ)
| Business Type | Manufacturer, Supplier |
| Body | Cast Iron |
| Connector | Cast Iron |
| Valve Seat | P.T.F.E. (Teflon) |
| Click to view more | |
Product Details
Ball
Stainless Steel
Spindle/Stem
Stainless Steel
Seal
P.T.F.E. (Teflon)
Nut
M.S.
Lever Lock
M.S.
Lever
M.S.
Lever Support
P.V.C.
Applications
Plumbing (Hot & Cold Water), Mining Industry, Construction Industry, Water & Effluent Treatment Plan
Product Code
H-11/BV
Features:
- 1/2” (15 mm) to 4” (100 mm) in screwed type 2 pc design
- Threads as per BSPT
- Stainless Steel mirror finish balls
- Blow-out proof stem
- P.T.F.E. seats and seals
- Gland Packing may be replaced under pressure
- Available in Cast Iron and Ductile Iron
- Full Bore Design
- Quick open\close by quarter turn operation.
Applications
- Plumbing (Hot & Cold Water), Mining Industry, Construction Industry, Water & Effluent Treatment
- Plants, Fire Fighting, Gas Suppliers, Solvent Plants, Distribution of Oils, Hydraulic Machines and for
- numerous other applications.
Bill of Material
| S.No. | Component | Material |
| 1 | Body | Cast Iron (IS:210) |
| 2 | Connector | Cast Iron (IS:210) |
| 3 | Valve Seat | P.T.F.E. (Teflon) |
| 4 | Ball | Stainless Steel (AISI-202/304/316) |
| 5 | Spindle/Stem | Stainless Steel (AISI-202/304/316) |
| 6 | Seal | P.T.F.E. (Teflon) |
| 7 | Nut | M.S. (IS: 226) |
| 8 | Lever Lock | M.S. (IS: 226) |
| 9 | Nut | M.S. (IS: 226) |
| 10 | Lever | M.S. (IS: 226) |
| 11 | Lever Support | P.V.C. |
Suitability
| Pressure Testing | |||||
| Test Pressure | Max C.W.P | ||||
| Body | Seat | Body / Seat | |||
| 500 PSI | 34 kg/cm² | 300 PSI | 20 kg/cm² | 200 PSI | 14 kg/cm² |
| # Hydraulically | |||||
|
Suitability : Air, Water, Gas, Oil, Temperature: 10 Degree to 200 Degree |
|||||
Dimensions
| DN SIZE | Dimensions | |||
| Inches | mm | X* | Y* | Z* |
| 1/2 | 15 | 78 | 70 | 130 |
| 3/4 | 20 | 85 | 77 | 141 |
| 1 | 25 | 95 | 81 | 147 |
| 1-1/4 | 32 | 115 | 102 | 164 |
| 1-1/2 | 40 | 125 | 104 | 165 |
| 2 | 50 | 143 | 117 | 190 |
| 2-1/2 | 65 | 158 | 153 | 199 |
| 3 | 80 | 173 | 162 | 207 |
| 4 | 100 | 305 | 152 | 325 |
| *Approx. dimensions in mm | ||||
| Note : All threads are BSPT/IS:554 | ||||
Chart
