20 Piece (MOQ)
| Business Type | Manufacturer, Supplier |
| Elbow | Malleable Iron |
| Nut | M.S. |
| Washer | M.S. & Synthetic Rubber |
| Click to view more | |
Product Details
Spindle
M.S.
Body
C.I.
Suitability
Water and Oil
DN SIZE (Inches)
1/2, 3/4
DN SIZE (mm)
15, 20
Applications
General industry, railway industry, construction industry, religious places, public places and other
Product Code
H-26/AWC
Features:
- Gravity operated self closiy type
- Threads as per BSPT
- Brass spindle & nut
- Synthetic rubber washer
- Powder coated long life paint
Applications:
- General industry, railway industry, construction industry, religious places, public places and
- other numerious applications
Bill of Material
| S.No. | Component | Material |
| 1 | Elbow | Malleable Iron |
| 2 | Nut | M.S. (IS: 3488) |
| 3 | Washer | M.S. (IS: 3488) |
| 4 | Washer | Synthetic Rubber (BS-2751) |
| 5 | Spindle | M.S. (IS: 3488) |
| 6 | Body | C.I. (IS:210) |
| 7 | Nut | M.S. (IS: 3488) |
Dimensions
| DN SIZE | Dimensions | ||
| Inches | mm | A* | B* |
| 1/2 | 15 | 73 | 126 |
| 3/4 | 20 | ||
| *Approx. dimensions in mm | |||
Suitability
| Test Pressure | Max CWP | ||
| Body | Seat | Body | Seat |
| 300 | 20 | 200 | 14 |
| PSI | kg/cm² | PSI | kg/cm² |
| Suitability : Water & Oil | |||
Chart
